ICL-Series-Rail-Mount-Hydraulic-Magnetic-Circuit-Breaker-Sensata

Designed specifically for 35mm DIN rail, Airpax ICL series Rail-Mount Hydraulic Magnetic circuit breakers offer the advantage of quick and easy mounting or removal which results in efficient and economical wiring while conserving space.

These circuit breakers are available in 1, 2, 3 pole models with a choice of handle colour with on/off and international I/O markings.

These breakers are approved to CCC, CCRC, UL (pending) and IEC (pending) standards. Typical applications include railway signalling, computers, telecom/datacom equipment, telecommunications, medical & industrial equipment etc. They provide the reliable performance associated with hydraulic magnetic circuit protection.

These circuit breakers are designed to mount on standard 35mm DIN rails, such as 35x7.5 or 35x15 DIN EN50022.

Features

  • Hydraulic-Magnetic technology
  • Up to 3 poles, 0.5 amps to 63 amps rated current at up to 415 VAC
  • CCC and CCRC approved
  • UL1077 recognized (supplementary breaker) (pending)
  • IEC approved (pending)
  • Up to 10,000AIC short circuit amperage rating
  • Available in various current and time delays
  • Precise trip characteristics
  • Trip indication with mid-trip position
  • Auxiliary and alarm switches are available

Product Documentation

ICL Series Rail-Mount Hydraulic Magnetic Circuit Breaker Data Sheet | PDF
LEJ-LEJA-Series-Sensata

The most compact hydraulic-magnetic circuit breaker rated at 240VAC per pole with a UL489 listing.

Higher voltage power architectures will be increasingly deployed in data center, telecom and other applications to improve energy efficiency and reduce operating expenses. The new Sensata Technologies LEJ/LEJA series offers critical protection in a compact, high performance solution at 240VAC per pole for higher efficiency power architectures.

Product Features & Benefits

  • 240VAC per pole in a compact and cost effective package for use in higher voltage architectures
  • Single and two pole construction up to 20 amps with 5KAIC rating provides design flexibility
  • Global Agency certifications including UL 489, CSA, TUV certified lo EN60947-2, CCC (pending)
  • Based on the proven performance and reliability of the industry leading LEG design
  • Panel cut out and mounting dimensions match those of the LEG design
  • Available with quick connects or screw terminals and toggle or rocker actuators
  • The low depth LEJA version improves the ease of assembly and wire routing in rack-mount power distribution units

Applications

  • Rack-mount power distribution units used in data center environments
  • AC power supplies used in telecommunication environments
  • Wide variety of industrial applications requiring 240VAC per pole

Product Documentation

LEJ/LEJA Series Hydraulic-Magnetic Circuit Breaker Data Sheet | PDF
209-Circuit-Breaker-Sensata

209 Series Magnetic Circuit Breaker

The 209, E-Frame circuit breaker combines power switching with accurate, reliable circuit protection in a compact single or multipole unit. The unit is ideal for branch circuit applications such as EDP, air conditioners, panel boards and lighting controls.

Product Documentation

209 Series Sensata Data Sheet | PDF

Sensata/Klixon & Airpax Circuit Breakers

209 Series Magnetic Circuit Breaker

The 209, E-Frame circuit breaker combines power switching with accurate, reliable circuit protection in a compact single or multipole unit. The unit is ideal for branch circuit applications such as EDP, air conditioners, panel boards and lighting controls.

Product Documentation

Sensata Klixon Airpax Circuit Breaker Catalogue | PDF

2TC-Sensata

Klixon® 2TC Series

1–25 amp, single–phase, miniature ambient compensated

  • Miniature size
  • Light weight
  • Trip–free design
  • Current ratings (1 to 25 amps)
  • High vibration resistance
  • High interrupting capacity
  • Coordinated ratings
  • AS58091 qualified (Also:Military Approvals, FAA PMA)
  • Typical end use: Aircraft power distribution systems

Product Documentation

2TC Klixon/Sensata Data Sheet | PDF

3TC-Sensata

Klixon® 3TC Series

15–35 amp, single–phase, miniature ambient compensated

  • Miniature size
  • Light weight
  • Trip–free design
  • Options include: longer push button, high vibration, random vibration, metric mounting thread, metric terminal thread, dust boot (part #14500-1 fits 15/32 bushing, part #14500-5 fits 7/16 bushing), terminal hardware
  • AS58091 qualified
  • Current rating: 15 to 35 amps
  • Coordinated ratings
  • High vibration resistance (option)
  • High interrupting capacity
  • Typical use: Where ambient temperature exceeds the 160°F (71°C) maximum of non–ambient compensated thermal circuit breakers

Product Documentation

3TC Klixon/Sensata Data Sheet | PDF

5BT-Thermostat-Sensata

5BT Series -65°F to 400°F, SPDT, Welded, Hermetically Sealed ½"

The Klixon 5BT series thermostat is a high reliability, hermetically sealed thermal switch. The single pole, double throw design allows versatility and economy in providing two functions within the same device. Typically these Klixon switches are used to control and indicate at a preset temperature. One pole can control a cooling fan and the other pole can indicate impending danger.

  • Single pole, double throw (SPDT)
  • Hermetically sealed
  • Vacuum baked and back–filled with nitrogen
  • High resistance to shock and vibration
  • Preset, non–adjustable calibration
  • Qualified to MIL-PRF-24236 /24

The 5BT thermostat is the ideal choice where quality and reliability in a double throw device are critical.


4344-Thermostat-Sensata

4344 Series Thermostats

Hermetically Sealed Thermostat

  • Snap-action switching
  • Rapid thermal response
  • Single pole, single throw
  • Normally open or normally closed
  • Pre-set, non-adjustable calibration
  • Various mounting configurations available
  • UL recognized, file #34618
  • CSA recognized, file #LR24458

Product Documentation

4344 Klixon/Sensata Data Sheet | PDF

M2-Thermostat-Sensata

Klixon® M2 Series Thermostats

0®F to 300®F, Narrow Differential, Hermetically Sealed ½"

  • Hermetically sealed
  • Vacuum baked and back–filled with dry nitrogen
  • Single pole, single throw (SPST)
  • Normally open or normally closed
  • Low profile
  • Narrow differential
  • Preset, non–adjustable calibration
  • Long cycle life (250,000 cycles)
  • Qualified to MIL-S-24236/20
  • Qualified to NASA S-311-641/02

Product Documentation

M2 Klixon/Sensata Data Sheet | PDF

M1 and 11041-Thermostat-Sensata

Klixon® M1 and 11041 Series Thermostats

½” Disc Hermetic Thermostats, -65°F to 550°F, SPST

  • Single Pole / Single Throw (SPST)
  • Preset temperature set points, non-adjustable calibration
  • High resistance to shock and vibration
  • Hermetically sealed, vacuum baked and back-filled with nitrogen
  • Various mounting configurations available
  • Qualified to MIL-PRF-24236/1

Product Documentation

M1 and 11041 Klixon/Sensata Data Sheet | PDF

3BT and 4BT-Thermostat-Sensata

Klixon® 3BT and 4BT Series Thermostats

0°F to 350°F, Tiny Stat™ Precision Thermostats

  • Smallest snap–acting thermal switches ever made
  • Extremely fast response
  • Single pole, single throw (SPST)
  • Normally open or closed
  • Preset, non-adjustable calibration
  • Hermetically sealed and back–filled with nitrogen
  • Gold plated
  • Various mounting configurations available
  • Qualified to MIL-PRF-24236/13 (4BT) and MIL-PRF-24236/19 (3BT)
  • Qualified to NASA S-311-641/06 (4BT) and NASA S-311-641/07 (3BT)

Product Documentation

3BT and 4BT Klixon/Sensata Data Sheet | PDF

5100-Thermostat-Sensata

5100 Series

Hermetically Sealed Thermostat Probe

  • RoHS compliant per EU directive 2002 / 95 / EC
  • ½” disc button style
  • Hermetic glass seal, isolated-case only
  • Ideal for immersion sensing

Product Documentation

5100 Klixon/Sensata Data Sheet | PDF

6700-Thermostat-Sensata

6700 Series

TO-220, Subminiature Bimetal Disc Thermostat

  • RoHS compliant per EU directive 2002 / 95 / EC
  • TO-220 / Y-220 international electronic package standard
  • Ideal for surface and air sensing on PC boards and heat sinks
  • VDE approved with “P” bracket option
  • Gold-plated contacts
  • Up to 20,000 life cycles @ max standard amperage
  • Up to 100,000 life cycles @ max gold contact amperage

Product Documentation

6700 Klixon/Sensata Data Sheet | PDF

6600-Thermostat-Sensata

6600 Series

8-Pin DIP, Subminiature Bimetal Disc Thermostat

  • RoHS compliant per EU directive 2002 / 95 / EC
  • 8-pin DIP international electronic package standard
  • Ideal for surface and air sensing on PC boards
  • Gold-plated contacts
  • Up to 30,000 life cycles @ max standard amperage (120VAC)
  • Up to 100,000 life cycles @ max gold contact amperage

Product Documentation

6600 Klixon/Sensata Data Sheet | PDF

1NT-Thermostat-Sensata

1NT Series

Fixed Temperature Thermostats

  • ISO9001: 2000 certification
  • Factory inspected for continuity and contact resistance
  • Global sales and technical support
  • Ambient temperature rating from 40°C to 240°C (-40°F to 464°F)
  • 1NT base provides:
    • Low cost
    • High temperature capability
    • Clean processing
    • High impact strength
    • Low static generation
  • Bi-metal disc is factory pre-set to achieve:
    • Operation at requested temperatures
    • Tamperproof settings
  • Product innovations include:
    • Solid metal-to-metal terminal construction
    • Current free spring
    • One piece transfer mechanism
  • Switch actions:
    • Automatic reset: Available with both normally open and normally closed switch logic
    • Manual reset: Mechanical reset device
    • Trip free manual reset: UL M2 class rating that resists consumer tampering
    • One shot: meets agency requirements for single operation device

Product Documentation

1NT Klixon/Sensata Data Sheet | PDF

3NT-Thermostat-Sensata

3NT Series

Fixed Temperature Thermostats

  • Single Pole / Single Throw (SPST)
  • Preset temperature set points, non-adjustable calibration
  • High resistance to shock and vibration
  • Hermetically sealed, vacuum baked and back-filled with nitrogen
  • Various mounting configurations available
  • Qualified to MIL-PRF-24236/1

Product Documentation

3NT Klixon/Sensata Data Sheet | PDF

20413-20600-20650-Fixed-Temperature-Thermostats-Sensata

20413, 20600 and 20650 Series

Fixed Temperature Thermostats - snap-action automatic or manual reset.

  • Klixon snap-action bimetal disc assures positive make/break action
  • Available with surface, thru-wall,well or cavity-type mountings
  • Temperature setting factory calibrated to your specifications
  • High capacity – up to 30 amps at 120, 240, and 277 VAC resistive
  • Extra high capacity – up to 40 amps at 120 and 240 VAC resistive

Product Documentation

20413-20600-20650 Klixon/Sensata Data Sheet | PDF

ACMP-Series-Thermostats-Klixon-Sensata

ACMP Series

Single–Phase and Three–Phase Aircraft Motor Protectors

  • Single– and three–phase protection
  • Locked rotor protection
  • Thermal protection
  • Neutral tap
  • Meets thermal protection requirements of MIL-M-7969, direct acting type, Method III

Product Documentation

ACMP Motor Protectors Klixon/Sensata Data Sheet | PDF
Klixon-Precision-Switches

Ideal for Extremely Harsh And Demanding Environments

  • Hermetically sealed
  • Excellent shock and vibration resistance
  • Switching up to 4 amps
  • Optimal for low level circuits
  • Temperature range between -275°F and 450°F
  • Lightweight
  • 30 VDC
  • Single and multiple pole designs available
  • Small, axi–symmetric design for robustness and reliability
  • Various mounting configurations for custom applications
  • Sealed and unsealed pushbuttons options
  • Available side plate designs for narrow width applications
  • Proven, reliable performance and long life
  • MIL-S-8805 qualification option

Klixon hermetic miniature and sub–miniature snap–action switches are ideal for extremely harsh and demanding environments as found in aircraft, military, aerospace, and aircraft engines applications.

Klixon’s precision hermetic switches have been used for over 40 years in a wide range of applications, and can be found on virtually all commercial and military aircraft, as well as various space vehicles and satellites worldwide.

We offer a wide choice of precision switches ideally suited for rugged applications. Sensata Technologies also manufactures a hermetically sealed snap–acting pressure switch line for applications in aerospace and electronics where high reliability and resistance to severe environments is essential.

  • 45–600 psia actuation pressures
  • Small and lightweight
  • High vibration and shock resistance
  • Corrosion resistant stainless steel construction
  • Snap–action switching
  • Available in standard or custom configurations

Applications

Hermetic switches are used for position indication in applications such as:

  • Aircraft landing gear and helicopter weight-on-wheels
  • Valve position indication in aircraft engines and APU’s
  • Aircraft environmental control systems and engine controls
  • Aircraft flight control surfaces
  • Stores away (munitions)
  • Door stairway indication
  • Brake controls
  • Parachute openers
  • Bomb racks and ejectors
  • APUs
  • Satellite panel indication and satellite arm indication
  • Pilot ejection seats
  • Missile launchers
  • Thrust reversers
  • Explosive actuators
  • EVA equipment
  • IUS platform
  • Hydraulic / servo controls
  • Engine valve indication
  • Gearboxes
  • Warhead safety circuits
  • Weapon firing systems and trigger switches
  • Rocket motor controls
  • Space station

KX-Precision-Switch-Kilixon-Sensata

Klixon® KX Series Sine Switch

  • Hermetic seal provides exceptional operational freedom from environmental conditions
  • Compactly designed to fit small, narrow spaces
  • Snap–acting Klixon sine switch provides exceptional resistance to shock and vibration
  • Available with either screw or solder lug type terminals
  • Embedded leads are available
  • Lead lengths can be supplied to customer requirements

Product Documentation

KX Series Data Sheet | PDF

AT-Precision-Switch-Kilixon-Sensata

Klixon® Basic AT Series Switches

  • Meet the demands of low-level current switching applications
  • Various mechanical and electrical configurations available as standard or custom configurations
  • Actuation plungers of various shapes and materials available
  • Multi-pole switch package options
  • Mounting via threaded brushings or side-plate design
  • Wiring can be supplied as flying leads or via a variety of standard connectors

Product Documentation

AT Series Data Sheet | PDF

6PS-Precision-Switch-Kilixon-Sensata

6PS Series Pressure Switches

-65°F to 275°F, maximum corrosion resistance under hostile conditions

  • Hermetically sealed per MIL-E-5400 paragraph 6.3.10
  • Covers actuation range of 45 to 600 PSIA
  • Miniature size and lightweight
  • High vibration resistance
  • Corrosion resistant: 300 series stainless steel construction for all environment and media exposed parts
  • Available in wide range of standard and custom configurations
  • 8000 psi minimum burst pressure
  • Typical use: maximum corrosion resistance under hostile conditions

Product Documentation

6PS Series Data Sheet | PDF
7AM-Thermal-Protector-Klixon-Sensata

7AM Series

Lighting, electrical, thermal, battery, motor protection/p>

  • Over 3 billion sold
  • Compact, miniature size
  • UL, CSA, KEMA (ENEC) approvals
  • Individually temperature checked on modern, custom-designed equipment
  • Positive make and break with Klixon snap–action disc
  • Repeatable temperature performance over life
  • Gasketed steel case suitable for most impregnation processes
  • Current and temperature sensitivity for maximum design flexibility and application
  • Wide selection of leads and insulating sleeves

Product Documentation

7AM Protectors Klixon/Sensata Data Sheet | PDF

17AM-Thermal-Protector-Klixon-Sensata

17AM Series

Thermal Protector

  • Shaded Pole Motor
  • Permanent split capacitor motor
  • Fluorescent lighting ballasts
  • HID ballasts
  • Transformer
  • Recessed lighting fixtures
  • Battery packs
  • Vacuum cleaners
  • Automotive accessory motors, solenoids, PC boards and other applications

Product Documentation

17AM Thermal Protectors Klixon/Sensata Data Sheet | PDF

6AP-Motor-Protector-Klixon-Sensata

6AP Series

Automotive Motor Protector

  • Snap–action Klixon disc
  • Thermal motor protection reacting to both current and temperature
  • Compact design
  • High cycle life and reliability
  • Terminal material provides trouble–free welding and in pre–tinned variation easy wavebath-soldering
  • Prevents overly high motor temperatures by providing very precise tripping times
  • Current–time characteristic optimized for each specific application
  • Protector selection and application testing by Sensata Technologies laboratory with results in extended report at your service
  • Protect 12– and 24–volt DC motors during locked rotor, overload and over–current situations
  • Wide variety of standard terminals configurations enable terminals to be welded, soldered or crimped
  • Custom configurations available including: open temperature, bimetal type, heater wire material, thickness
  • Custom design flexibility including customer part number printed on product and color coding

Product Documentation

6AP Motor Protectors Klixon/Sensata Data Sheet | PDF

4CR-Motor-Starting-Relay-Klixon-Sensata

4CR Series

Starter Relay Motor Protector for AC starter relays up to 25 amps

Features and Overview

  • Reliable operation
  • Long life independent of mounting position
  • Start winding current rating: 25 amps
  • Wide range of pick–up and drop–out ratings
  • Small size for installation in compact equipment
  • Economical

Product Uses


MA10-Thermal-Cut-Out-Klixon-Sensata

MA10 Series

Motor protector and thermal cut–out - 250VAC - 12 A resistive

Features and Overview

  • Snap–action Klixon disc is exposed
  • ENEC, UL, CSA approvals
  • Compact design for easy mounting
  • Cost effective and reliable protection
  • Available in wide range of calibrated pre-set operating temperatures with varying tolerances
  • A high, middle, or low current-sensitive bimetal disc is available at no additional charge
  • Fast thermal response

For over 30 years the Sensata Technologies MA10 has provided reliable protection in a variety of small domestic and personal care appliances. The MA10 has set the world standard in the field of open type temperature–sensitive safety cut–outs.


Product Documentation

MA10 Klixon/Sensata Data Sheet | PDF

2MM-Motor-Protector-Thermal-Cut-Out-Klixon-Sensata

2MM Series

Battery protector and thermal cut–out - 250VAC 7 (2.0) A

Features and Overview

  • Snap–action Klixon disc: field proven, reliable and repeatable snap–action bimetal actuation
  • ENEC, BEAB, CSA approvals
  • 120VAC and 230VAC
  • Low profile shape for close coupling to on– or in–winding applications
  • Competitive performance to price ratio: maximum quality and reliability at a cost effective price
  • Maximum protection under locked rotor and overload conditions
  • Compact size for ease of installation, even in small places
  • Available in two versions: with epoxy insulation and with additional sleeve

Product Documentation

2MM Battery Protector Klixon/Sensata Data Sheet | PDF

3MP-Motor-Protector-Thermal-Cut-Out-Klixon-Sensata

3MP Series

Motor protector and thermal cut–out - 250VAC 6(1)A

Features and Overview

  • Snap–action Klixon disc
  • ENEC, BEAB, UL, CSA approvals
  • 120VAC and 230VAC
  • Compact design
  • Minimizes the total cost of the motor protection function
  • Maximum protection under locked rotor conditions
  • Provides extra flexibility during the motor manufacturing process
  • Reduces the total need of motor protector type: one code for several applications
  • Provides mounting flexibility and ease of handling
  • Ensures trouble–free soldering and welding
  • Low–cost solution for transformer protection
  • Long life and reliable cycling
  • Wide range of standard lead configuration available
  • Wide range of customization available, including: leads, Mylar™ insulation sleeve, coding, colors

Product Documentation

3MP Motor Protector Klixon/Sensata Data Sheet | PDF

3MP-Motor-Protector-Thermal-Cut-Out-Klixon-Sensata

3MP Self-Hold Series

Motor protector and thermal cut–out - Self–hold, 250VAC 6(1)A

Features and Overview

  • Snap–action Klixon disc
  • ENEC and UL approvals
  • 120VAC and 230VAC
  • Compact design
  • Minimizes the total cost of the motor protection function
  • Provides higher level of safety for appliances having free access to rotating parts
  • Provides extra flexibility during the motor manufacturing process
  • Provides mounting flexibility and ease of handling
  • Guarantees to pass the UL 18 days locked rotor test in combination with high currents
  • Assures maximum protection under locked rotor conditions
  • European supply
  • Wide range of standard lead configuration available
  • Wide range of customization available, including: terminal configurations, leads, Mylar™ insulation sleeve, coding, colors

Product Documentation

3MP Self-Hold Motor Protector Klixon/Sensata Data Sheet | PDF

TH10-Thermal-Cut-Out-Klixon-Sensata

TH10 Series

Thermal Cut–Outs - Automatic 250V-13(2)A and 250V-30(5)A

Features and Overview

  • Snap–action Klixon disc
  • ENEC, UL, CSA approvals
  • Wide temperature range: 45°C to 170°C
  • Standard 5K tolerance
  • Different bimetal resistivity
  • Robust design: bimetal disc is protected by nickel–plated steel supports for superior cycling performance
  • Full automated live: Provides stable setting values
  • Low price: This particular design provides high competitively
  • Flexible mounting with three terminal configurations available: on same end, on opposite end, on opposite end with holes
  • Self–hold version is available as the TH11 or TH21 series: Identical construction but resistive material on one ceramic pin (identical dimensions mean that the TH10, TH11, andTH21 can be easily exchanged with one another)

Product Documentation

TH10 Thermal Cut–Out Klixon/Sensata Data Sheet | PDF

TH11-TH21-Self-Hold-Thermal-Cut-Outs-Klixon-Sensata

TH11 and TH21 Series

Thermal Cut–Outs - Self–hold 250V-16(2)A

Features and Overview

  • Snap–action Klixon disc
  • ENEC, UL, CSA approvals
  • Wide temperature range
  • Standard 5K tolerance
  • Different bimetal resistivity
  • Robust design: bimetal disc is protected by nickel-plated steel supports for superior cycling performance
  • Full automated live: Provides stable setting values
  • Low price: This particular design provides high competitively
  • Flexible mounting with three terminal configurations available: on same end, on opposite end, on opposite end with holes
  • Automatic reset version is available as the TH10 series(identical dimensions mean that the TH10, TH11, and TH21 can be easily exchanged with one another)
  • TH11 operates at 230VAC, TH21 is designed for 120VAC applications

Product Documentation

TH11 & TH21 Thermal Cut–Out Klixon/Sensata Data Sheet | PDF

YS10-Thermal-Cut-Outs-Klixon-Sensata

YS10 Series

Thermal Cut–Outs - High current capacity small thermostat protector

Features and Overview

  • Snap–action Klixon disc
  • ENEC, UL, CSA, CQC, MITI approvals
  • High current capacity (125Vac/16A) to cut off power circuit
  • Has small size and thermal sensitivity of conventional MA10 protector
  • Temperature range: 60°C to 150°C
  • Reliable long life
  • Automatic reset thermal cut-out (type 2C)

YS10 was developed to protect people and property from accidents occuring in hair dryers, fan heaters, and other products.

Product Documentation

YS10 Thermal Cut–Out Klixon/Sensata Data Sheet | PDF

9700-Thermal-Protector-For-Motor-Florescent-Ballasts-And-Temperature-Sensing-Controls-Klixon-Sensata

9700 Series

Thermal protector for motors, fluorescent ballasts, temperature sensing controls - Up to 18 amps AC on–winding motor protector

Features and Overview

  • Snap–action Klixon bimetal disc: Positive make and break is assured with proven Klixon strip disc, contact pressure at open temperature eliminates nuisance trips due to vibration
  • Miniature size: compact design assures ease of installation
  • Precision calibration: Temperature calibrated and inspected in controlled ambients for dependable consistent performance
  • Sealed steel case: withstands impregnation and baking, can be varnish dipped, prevents changes in calibration during installation
  • Options include: contact ratings of up to 18 amps for harsh environments; Mylar sleeves (shrinkable or non-shrinkable); electrical configurations, leads, and more
  • UL, CSA, BEAB, VDE, SEMKO certifications on 9700K model
  • ISO 9001

The Klixon 9700 protector is a field proven miniature protector developed to protect electrical equipment against overheating.

In addition to being small and lightweight, the unit is both temperature and current sensitive. Since the 9700 is sealed to withstand varnish dipping, it can be mounted directly in windings where it can best sense the true temperature of the electrical equipment. As a result, over-temperature protection is assured.

Since the case is not electrically insulated, the protector is furnished with a durable Mylar insulating sleeve. Shrinkable and non-shrinkable sleeves are available.

Product Documentation

9700 Thermal Motor Protector Klixon/Sensata Data Sheet | PDF
PS80-Automatic-Reset-Pressure-Switches-Klixon-Sensata

PS80 Series

HVAC/R, commercial, and industrial uses / -20°F to 150°F, automatic reset pressure switch

Features and Overview

  • Epoxy–less seal
  • Flexible range of set–points and tolerances
  • Factory calibrated fixed set–points
  • Single–pole, single–throw switch; normally open or closed contacts
  • Hermetically sealed sensor

Product Documentation

PS80 Klixon/Sensata Data Sheet | PDF

PS80-Automatic-Reset-Pressure-Switches-Klixon-Sensata

PS80-2X Series

CO2 pressure switches - For use in R744/CO2 operated systems

Features and Overview

  • Hermetically sealed
  • Environmentally sealed leads
  • Reliable over broad pressure and temperature ranges
  • Factory calibrated settings
  • Single–pole, single–throw switch; normally open or closed contacts
  • Proven reliability

Leading the world in switch design. The PS80-2X is an automatic reset pressure switch designed to meet the unique challenges of R744/COs-based air conditioning and refrigeration equipment. These green systems require robust switches capable of withstanding the increased pressures and temperatures generated by these units. Sensata has redesigned the flagship PS80 to meet the special requirements of these transcritical R744 systems

Product Documentation

PS80-X2 Pressure Switch Klixon/Sensata Data Sheet | PDF

20PS-39PS-40PS-41PS-Pressure-Switches-Klixon-Sensata

20PS Series

HVAC/R, commercial, and industrial uses / -20°F to 150°F, automatic reset pressure switch

Features and Overview

  • Single pole, single throw switch normally open or closed contacts
  • Factory calibrated pressure setpoints from vacuum to 750 psig (52 Bar)
  • Snap–acting, stainless steel
  • Hermetically sealed sensor
  • Environmentally sealed or vented switch

This compact, rugged switch utilizes a snap–acting stainless steel diaphragm that reverses its curvature when pressurized to a customer specified actuation pressure. When the disc snaps it opens or closes a set of electrical contacts by means of a transfer pin. Resetting the switch occurs automatically when pressure drops below the release value.

Product Documentation

20PS Pressure Switch Klixon/Sensata Data Sheet | PDF

20PS-39PS-40PS-41PS-Pressure-Switches-Klixon-Sensata

29PS Series

HVAC/R, commercial, and industrial uses / -20°F to 150°F, manual reset pressure switch

Features and Overview

  • Trip–free manual reset
  • Maintenance–free design
  • Single–pole, single–throw, normally closed contacts
  • Factory calibrated pressure set points
  • Hermetically sealed sensor

The 29PS utilizes a snap–acting stainless steel Klixon disc that reverses its curvature when pressurized above a customer specified actuation pressure. When the disc snaps it opens a set of electrical contacts by means of a transfer pin. Resetting of the switch must be accomplished manually by pressing the integrated reset button.

Product Documentation

29PS Pressure Switch Klixon/Sensata Data Sheet | PDF

6PS-Precision-Switch-Kilixon-Sensata

6PS Series

Pressure switch / -65°F to 275°F, maximum corrosion resistance under hostile conditions

Features and Overview

  • Hermetically sealed per MIL-E-5400 paragraph 6.3.10
  • Covers actuation range of 45 to 600 PSIA
  • Miniature size and lightweight
  • High vibration resistance
  • Corrosion resistant: 300 series stainless steel construction for all environment and media exposed parts
  • Available in wide range of standard and custom configurations
  • 8000 psi minimum burst pressure
  • Typical use: maximum corrosion resistance under hostile conditions

Klixon 6PS Series precision pressure switches are snap–acting, all–welded devices with hermetically sealed switch contacts. They were developed for applications in aerospace and electronics where high reliability and/or resistance to severe environments is required.

Product Documentation

6PS Pressure Switch Klixon/Sensata Data Sheet | PDF

2CP-HVAC-Refrigeration-Pressure-Sensor-Sensata

2CP Series

Pressure switch

The 2CP5/2CP50 Series is ideal for demanding Air Conditioning and Refrigeration applications where long-term reliability & accuracy is a must. This series provides proven reliability at a competitive price.

Product Documentation

2CP Pressure Switch Klixon/Sensata Data Sheet | PDF

112CP-Combined-Pressure-Temperature-Sensor-Sensata

112CP Series

Combined Pressure/Temperature Sensor

The 112CP series combined pressure/temperature sensor delivers the benefit of both pressure and in-stream temperature sensing in a single, robust integrated package.

Product Documentation

112CP Combined Pressure/Temperature Sensor Klixon/Sensata Data Sheet | PDF

3PP8-Hermetic-Pressure-Sensor-Sensata

3PP8 Series

Automotive Silicon MEMs Strain Gage Hermetic Pressure Sensing

  • Silicon MEMs strain gage sensor
  • Temperature compensated and accurate performance over a wide temperature range
  • EEPROM memory: stores calibration coefficients and serialization
  • Expanded user diagnostic capability
  • Available in pressure ranges from 0–500 and 0–5,000 psis
  • Available in a variety of thread configurations

Product Documentation

3PP8 Automotive Hermetic Pressure Sensing Klixon/Sensata Data Sheet | PDF
